Product Details
expand_less
| Ground Electrode Quantity |
1 |
| Thread Diameter |
0.472 |
| Part Number |
DR8EIX |
| Heavy Duty Supplier |
Yes |
| Service Number |
DR8EIX |
| Ground Configuration |
J-Gap |
| Washer Included |
Yes |
| Center Electrode Core Material |
Copper Core |
| Short Style Spark Plug |
No |
| Seat Type |
Gasket |
| Center Electrode Tip Material |
Iridium |
| Insulator Height |
1.99 |
| Ground Electrode Core Material |
Nickel Core |
| Skirt Length |
0.0 |
| Material Grade |
Iridium |
| Resistor Type |
Yes |
| Alliance Keywords |
spark plug, bougie d'allumage, bougie |
| Manufacturer Heat Range |
8 |
| Reach |
19.0 |
| Ground Electrode Tip Design |
Taper Cut |
| Electrical Terminal Type |
Stud |
| Thread Size |
M12 - 1.25 |
| Resistance |
5000.00 |
| Gap Size |
0.8 |
| Insulator Material |
Ceramic |
| Stock Number |
6681 |
| Metallurgy |
Single Iridium |
| Grade Type |
Performance |
| Hex Size |
18mm |
| Part Terminology |
Spark Plug |
Features & Benefits
expand_more
NGK Iridium IX spark plugs are specifically designed for the performance enthusiast. Iridium IX provides outstanding acceleration, high fuel efficiency and durability. NGK Iridium IX plugs offer extreme ignitability and exceptional anti-fouling. Tapered cut ground electrode provides improved starting, idling and throttle response. The Iridium fine wire center electrode's durability is six times harder than platinum. Iridium alloy's extremely high melting point is perfect for today's engines. For even greater performance consider upgrading to an NGK Ruthenium HX plug.
Application Summary
expand_more
ATV - 2002-99 BRP, 2008-81 HON, 2009-85 KAW, 2007-02 KYMCO, 2004-85 SUZ, 2008-87 YAM, M/C - 2004-85 APRILIA, 2004-96 BMW, 1985-84 CAN AM, 1990-85 DUCATI, 2002-70 HON, 1986-84 HUSQ, 2006-80 KAW, 2002-93 KTM, 2008-78 SUZ, 2008-75 YAM
